V-TAC · SUN-3K-G04P1-EU-AM1
● ON REQUEST · CHECK AVAILABILITY

3kW On Grid Solar Inverter Single Phase

3kW On Grid Solar Inverter Single Phase with IP65 protection and an operating range of -25 to +65℃, >45℃ Derating. 5 years; certification on file: Declaration of Conformity, EMC License and LVD License.

EXCL. VAT · LIST PRICE
TierYour priceTerms
A verified trade account shows prices and tier discounts of 0, 5, 10 and 15%. Approval takes up to one business day.🔒 Unlock trade pricing
MANUFACTURER WARRANTY
5 years
The manufacturer's own terms and conditions apply. We administer the claim — see the terms of sale.
CERTIFICATION · 3
Declaration of ConformityEMC LicenseLVD License

Technical specification

ELECTRICAL DATA12 items
Max. PV Input Power3.9kW
Rated AC Output Active Power3 kW
Max. Operating PV Input Current20A
Max. Input Short Circuit Current30A
Max. PV Input Voltage550V
MPPT Voltage Range70-500V
Rated PV Input Voltage360V
Start-Up Voltage80V
Rated Output Voltage/Range220/230 0.85Un-1.1Un
Rated Output Grid Frequency/Range(Hz)50/45-55, 60/55-65
Power Factor0.8 leading to 0.8 lagging
PhaseSingle Phase
PHYSICAL DATA3 items
Working conditions-25 to +65℃, >45℃ Derating
IP RatingIP65
Size280 x 310 x 184 (Excluding Connectors and Brackets)
CERTIFICATIONS & WARRANTY3 items
Warranty5 years
ZEREZ registration no.ZE-KAXY-9P71-0007 (VDE-AR-N 4105:2018-11)
ZEREZ register checked on2026-10-26
PACKAGING2 items
Item Weight6.35 kg
Items per box1
PRODUCT DATA3 items
Order code11957
Product codeSUN-3K-G04P1-EU-AM1
BrandDeye
Request price & availability
